HDPE Pipe Manufacturers in Delhi

HDPE Pipes

Hdpe (High-Density Polyethylene) is Polymer used for Extrusion process of Hdpe Pipes also termed as PE Pipes.

Berlia Pipes is committed to offer best in class pipes to the customers, as we use prime grade raw material for Production and pipes are duly tested in our laboratory on regular intervals.

Hdpe Pipes are one of the most economical and durable option for industries such as Water Sewage, Gas Transportation, Water Supply, Drainage, Cable Laying, Irrigation, etc. .

Pipes manufactured in our Production Facilities are in Compliance with Indian, American, British Standards and all necessary tests are performed accordingly before any dispatch schedule. .

Pipes are available in standard length of 6 / 10 / 12 Meters and also available in coil form upto 500 / 1000 Meters. .

PE Pipes are available with or without Anti- Rodent, Ultra Violet, Fire retardant as per the customer requirements. Tailor made Pipes are also available as per requirements.

Range:

  • Standards: ISO, DIN, ASTM, ISI, BIS.
  • Diameter: 20 mm - 500 mm (1/2” to 20”)
  • Pressure rating from: PN 2. 5 to 16, SDR 6 to 41

Different Pipes Category that we manufacture are:-

  • Hdpe Pipes (IS: 14333:1996)
  • Hdpe Pipes (IS: 4984:2016)
  • Hdpe Pipes (IS: 14151)
  • Hdpe Pipes (ISO 4427 Pt-2)
HDPE PIPE (IS: 14333:1996)

  • Pe Pipes in compliance to IS: 14333:1996 are generally used for Drainage, Sewage, disposal of corrosive effluent waste, ash slurry conveyance, etc.
  • These pipes are without blue strips and are black in colour as per standards.
  • Pipes are available in standard length of 6 / 10 / 12 Meters; special lengths can be manufactured on request.
  • Range available: 63 mm to 500 mm (2”-20”).
  • Pipes are manufactured from prime grade PE63/80/100 material.
  • The pipes are joined either by click ring type fittings or by butt welding, thus absolutely watertight.
  • Few Features for Pe Pipes are as Low installation cost, Low frictional losses, Long System Life, suitable for extreme site conditions, Resistance to impact, chemicals & salt in water.
HDPE Pipe (IS:4984-2016)

  • Pe Pipes in compliance to IS: 4984:2016 are generally used for Portable Water Supply, Irrigation, Cable Laying, etc.
  • These pipes are with blue strips and are black in colour as per standards.
  • Pipes are available in standard length of 6, 10, 12 Meters; Coils Available upto 110 mm, special lengths can be manufactured on request.
  • Range available: 20 mm to 500 mm (1/2”-20”).
  • Pipes are manufactured from prime grade PE63/80/100 material.
  • The pipes are joined either by click ring type fittings or by butt welding, thus absolutely watertight.
  • Few Features for Pe Pipes are as Low installation cost, Low frictional losses, Long System Life, suitable for extreme site conditions, Resistance to impact, chemicals & salt in water.
HDPE Pipe (IS:14151)

  • Pe Pipes in compliance to IS: 14151 are generally used for Irrigation, Sprinkler Systems, Temporary Water Transportation Systems, etc.
  • These pipes are without blue strips and are black in colour as per standards.
  • Pipes are available in standard length of 6 Meters; special lengths can be manufactured on request.
  • Range available: 63 mm to 500 mm (2”-20”).
  • Pipes are manufactured from prime grade PE63/80/100 material.
  • The pipes are joined either by butt welding or Sprinkler Coupled Systems which is provided with the Pipes.
  • Few Features for Pe Pipes are as Easy Installation, Light Weight.
  • Suitable for portable impact overhead and floppy sprinkler systems
  • Can be used for portable water supply distribution pipelines
  • Can be used for temporary piping systems
  • All weather installation or disassembly suitable for extreme site conditions
  • Low installation cost
  • Low frictional losses
  • Long System Life
  • Resistance to impact
HDPE Pipe (IS:4427 Pt-2)

  • Hdpe Pipes manufactured as per ISO 4427 Pt-2 (International Standards) are the most commonly asked and referred Pipes.
  • PIPES are generally used for Water Supply Intended for Human Consumption, including conveyance of raw water prior to treatment and that of water for general purpose.
  • Range available: 63 mm to 500 mm (2”-20”).
  • Pressure Ratings: SDR 6 to SDR 41
  • These Pipes can by joined using Butt Welding technique.
  • Pipes are available in Coil and Straight Length upto 12 Meters.
  • Colour: Black, Blue.
